unity开发——打飞碟小游戏

项目地址

https://github.com/goodhuahua/unity-game/tree/master/飞碟游戏

游戏规则及要求

规则

正常模式共有五轮飞碟，飞碟数列遵循斐波那契数列，当所有飞碟发射完毕时游戏结束。

无限模式拥有无限轮数

红色飞碟为4分，黄色飞碟为3分，绿色飞碟为2分，蓝色飞碟为1分。

物理学模式下飞碟会互相碰撞

要求

使用带缓存的工厂模式管理不同飞碟的生产与回收，该工厂必须是场景单实例的！具体实现见参考资源 Singleton 模板类
近可能使用前面 MVC 结构实现人机交互与游戏模型分离

设计模式讲解

这次开发我们继续沿用原来使用过的设计模式，并在原设计模式基础上添加新的设计模式

首先我们回顾下原来的设计模式UML图：

对象池：

• DiskFactory 类是一个单实例类，用前面场景单实例创建
• DiskFactory 类有工厂方法 GetDisk 产生飞碟，有回收方法 Free（Disk）
• DiskFactory 使用模板模式根据预制和规则制作飞碟
• 对象模板包括飞碟对象与飞碟数据

在原来的基础上，我们这次的游戏引入了场景单实例和飞碟工厂类，最后新的UML图大致如下：

代码剖析

复用的框架代码不再重复讲解，只针对本游戏的核心代码进行讲解。

伪代码

getDisk(ruler)
BEGIN
	IF (free list has disk) THEN
	a_disk = remove one from list
	ELSE
	a_disk = clone from Prefabs
	ENDIF
	Set DiskData of a_disk with the ruler
	Add a_disk to used list
	Return a_disk
END
FreeDisk(disk)
BEGIN
	Find disk in used list
	IF (not found) THEN THROW exception
	Move disk from used to free list
END

Disk

完成飞碟对象的创建

public class Disk : MonoBehaviour
{
    public GameObject disk;
    //public DiskData data;
    public Disk(string name){//四种飞碟
        if(name == "disk1"){
                disk = GameObject.Instantiate(Resources.Load<GameObject>("disk1"), Vector3.zero, Quaternion.identity) as GameObject;
                disk.AddComponent<DiskData>();
                //data=disk.GetComponent<DiskData>();
                disk.GetComponent<DiskData>().points=1;
                disk.GetComponent<DiskData>().direction=new Vector3(UnityEngine.Random.Range(-1f, 1f) > 0 ? 2 : -2, 1, 0);
                disk.GetComponent<DiskData>().speed=1.0f;
            }
            else if(name == "disk2"){
                disk = GameObject.Instantiate(Resources.Load<GameObject>("disk2"), Vector3.zero, Quaternion.identity) as GameObject;
                disk.AddComponent<DiskData>();
                //data=disk.GetComponent<DiskData>();
                disk.GetComponent<DiskData>().points=2;
                disk.GetComponent<DiskData>().direction=new Vector3(UnityEngine.Random.Range(-1f, 1f) > 0 ? 2 : -2, 1, 0);
                disk.GetComponent<DiskData>().speed=2.0f;
            }
            else if(name == "disk3"){
                disk = GameObject.Instantiate(Resources.Load<GameObject>("disk3"), Vector3.zero, Quaternion.identity) as GameObject;
                disk.AddComponent<DiskData>();
                //data=disk.GetComponent<DiskData>();
                disk.GetComponent<DiskData>().points=3;
                disk.GetComponent<DiskData>().direction=new Vector3(UnityEngine.Random.Range(-1f, 1f) > 0 ? 2 : -2, 1, 0);
                disk.GetComponent<DiskData>().speed=3.0f;
            }
            else if(name == "disk4"){
                disk = GameObject.Instantiate(Resources.Load<GameObject>("disk4"), Vector3.zero, Quaternion.identity) as GameObject;
                disk.AddComponent<DiskData>();
                disk.GetComponent<DiskData>().points=4;
                disk.GetComponent<DiskData>().direction=new Vector3(UnityEngine.Random.Range(-1f, 1f) > 0 ? 2 : -2, 1, 0);
                disk.GetComponent<DiskData>().speed=4.0f;
            }
            //return disk;
        }
    public GameObject getGameObject(){return disk;}
}

DiskData

飞碟的数据，携带飞碟的飞行速度、得分、以及飞行方向。

public class DiskData: MonoBehaviour
{
    public float speed;//飞行速度
    public Vector3 direction;//初始飞行方向
    public int points;//得分
}
DiskFactory
负责生产和释放飞碟

public class DiskFactory : MonoBehaviour
{
    // Start is called before the first frame update
    List<DiskData> used;
    List<DiskData> free;
    public void Start(){
        used = new List<DiskData>();
        free = new List<DiskData>();
    }
    public GameObject GetDisk(){
        Debug.Log("get...\n");
        Disk disk=null;
        GameObject d;
        int rand=Random.Range(0,99);//生成一个随机数
        if(free.Count>0){//若还有空闲的飞碟，就将其加入
            Debug.Log("free...\n");
            d=free[0].gameObject;
            //disk.getGameObject().SetActive(true);
            free.Remove(free[0]);
        }
        else{
            Debug.Log("new...\n");
            if(rand%4==0){
                disk=new Disk("disk1");
            }
            else if(rand%4==1){
                disk=new Disk("disk2");
            }
            else if(rand%4==2){
                disk=new Disk("disk3");
            }
            else{
                disk=new Disk("disk4");
            }
            d=disk.getGameObject();
        }
        used.Add(d.GetComponent<DiskData>());
        return d;
    }
    public void FreeDisk(GameObject disk){
        for(int i=0;i<used.Count;i++){
            if(disk.GetInstanceID() == used[i].gameObject.GetInstanceID()){
                //used[i].getGameObject().SetActive(false);
                disk.SetActive(false);
                used.Remove(used[i]);
                free.Add(used[i]);
                break;
            }
        }
    }
}

IUserAction

包含对运动学和物理学的飞行模式的切换，是否将游戏设置为无穷模式，控制飞碟的点击得分。

public interface IUserAction
{
	void setFlyMode(bool isPhysis);//设置飞行模式
    void Hit(Vector3 position);//点击
    void Restart();//重置
    void SetMode(bool isInfinite);//选择模式
    bool Check();
    int GetPoints();
}
FirstController
对接口的函数的实现

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class FirstController : MonoBehaviour, ISceneController, IUserAction {

DiskFactory diskFactory;
RoundController roundController;
//UserGUI userGUI;
public IActionManager actionManager;
public int points;
void Awake () {
	SSDirector director = SSDirector.getInstance ();
	director.setFPS (60);
    points=0;
	director.currentSceneController = this;
    LoadResources ();
}
// loading resources for first scence
public void LoadResources () {
	UnityEngine.Debug.Log("load...\n");
    //获得对象
    diskFactory=Singleton<DiskFactory>.Instance;
    roundController=Singleton<RoundController>.Instance;
}

public void Pause ()
{
	throw new System.NotImplementedException ();
}

public void Resume ()
{
	throw new System.NotImplementedException ();
}

public void FreeDisk(GameObject disk){
    diskFactory.FreeDisk(disk);
}

#region IUserAction implementation
public bool Check(){//检查比赛是否结束
    return roundController.isEnd;
}
public void Hit(Vector3 position){//光标拾取多个物体
    Camera ca = Camera.main;;
	Ray ray = ca.ScreenPointToRay(position);
    //将飞碟移至底端，触发动作回调
    //移动位置
    //积分
       //更新GUI数据,更新得分
		RaycastHit hit;
		if (Physics.Raycast(ray, out hit)) {
			print (hit.transform.gameObject.name);
			if (hit.collider.gameObject.GetComponent<DiskData>() != null) { //plane tag
				Debug.Log ("hit " + hit.collider.gameObject.name +"!" );
                //将飞碟移至底端，触发动作回调
                //移动位置
                hit.collider.gameObject.transform.position=new Vector3(0,-7,0);
                //积分
                roundController.Record(hit.collider.gameObject.GetComponent<DiskData>());
                points=roundController.GetPoints();
			}

		}

}
public int GetPoints(){
    return points;
}
public void Restart()//游戏重新开始
{
    //userGUI.SetMessage(" ");
    //清零得分
    //userGUI.SetPoints(0);
    roundController.Reset();
    points=0;

}

public void SetMode(bool isInfinite){
    roundController.SetMode(isInfinite);
}

public void setFlyMode(bool isPhysis){
    roundController.setFlyMode(isPhysis);
}
#endregion
void Update(){

}

}

IActionManager

对飞行动作的实现

public interface IActionManager
{
    void Fly(GameObject disk,float speed,Vector3 direction);
}
CCFlyAction
运动学的飞行动作

public class CCFlyAction : SSAction
{
	public Vector3 direction;
	public float speed;
	float gravity;
	float time;
    //public FirstController sceneController;

public static CCFlyAction GetSSAction(Vector3 direction,float speed){
	CCFlyAction action = ScriptableObject.CreateInstance<CCFlyAction> ();
	action.direction=direction;
	action.speed=speed;
	action.gravity=9.8f;
	action.time=0;
	return action;
}

public override void Update ()
{
	//获取上一帧渲染所消耗的时间
	time+=Time.deltaTime;
	//使物体沿着重力方向下落
	transform.Translate(Vector3.down*gravity*time*Time.deltaTime);
	//在每一帧更新物体的位置,使运动与帧率无关
	transform.Translate(direction*speed*Time.deltaTime);
	// this.transform.position = Vector3.MoveTowards (this.transform.position, target, speed * Time.deltaTime);
	if (this.transform.position.y < -10) {//如果飞碟到达底部，则动作结束，回调
		//waiting for destroy
		this.enable=false;
		this.destory = true;
		this.callback.SSActionEvent (this);
	}
}
public override void Start () {
	//将对象设为刚体
	gameobject.GetComponent<Rigidbody>().isKinematic=true;
}

}

CCActionManager

对运动学飞行动作的实现和控制

public class CCActionManager : SSActionManager, ISSActionCallback, IActionManager{

private FirstController sceneController;
public CCFlyAction flyAction;

protected new void Start() {
	sceneController = (FirstController)SSDirector.getInstance ().currentSceneController;
	sceneController.actionManager=this;
}

// Update is called once per frame
public void Fly(GameObject disk,float speed,Vector3 direction){//实现飞行动作
	flyAction=CCFlyAction.GetSSAction(direction,speed);
	RunAction(disk,flyAction,this);
}

#region ISSActionCallback implementation
public void SSActionEvent (SSAction source, SSActionEventType events = SSActionEventType.Competeted, int intParam = 0, string strParam = null, Object objectParam = null)
{
	//飞碟结束飞行后回收飞碟
	sceneController.FreeDisk(source.gameobject);
}
#endregion

}

PhysisFlyAction

对物理学飞行动作的实现

public class PhysisFlyAction : SSAction
{//实现物体的物理学飞行，增加一个水平初速度即可
    float speed;//水平速度
    Vector3 direction;//飞行方向
    public static PhysisFlyAction GetSSAction(Vector3 direction,float speed){
		PhysisFlyAction action = ScriptableObject.CreateInstance<PhysisFlyAction> ();
		action.direction=direction;
		action.speed=speed;
		return action;
	}
    // Start is called before the first frame update
    public override void Start()
    {
        //增加一个水平初速度
        gameobject.GetComponent<Rigidbody>().velocity=speed*direction;
    }

// Update is called once per frame
public override void Update()
{
    if (this.transform.position.y < -10) {//如果飞碟到达底部，则动作结束，回调
		//waiting for destroy
		this.enable=false;
		this.destory = true;
		this.callback.SSActionEvent (this);
	}
}

}

PhysisActionManager

对物理学飞行动作的控制

public class PhysisActionManager : SSActionManager, ISSActionCallback, IActionManager{

private FirstController sceneController;
public PhysisFlyAction flyAction;

protected new void Start() {
	sceneController = (FirstController)SSDirector.getInstance ().currentSceneController;
	sceneController.actionManager=this;
}

// Update is called once per frame
public void Fly(GameObject disk,float speed,Vector3 direction){//实现飞行动作
	disk.GetComponent<Rigidbody>().isKinematic = false;
	disk.GetComponent<Rigidbody>().useGravity = true;
	flyAction=PhysisFlyAction.GetSSAction(direction,speed);
	RunAction(disk,flyAction,this);
}

#region ISSActionCallback implementation
public void SSActionEvent (SSAction source, SSActionEventType events = SSActionEventType.Competeted, int intParam = 0, string strParam = null, Object objectParam = null)
{
	//飞碟结束飞行后回收飞碟
	sceneController.FreeDisk(source.gameobject);
}
#endregion

}

ScoreRecorder

对得分的控制

public class ScoreRecorder
{
    static int points=0;//记录游戏当前比分
    public ScoreRecorder(){
        points=0;
    }
    public void Record(DiskData disk){
        //Debug.Log("1\n");
        points +=disk.points;
    }
    public int GetPoints(){
        return points;
    }
    public void Reset(){
        points=0;
    }
}
RoundController
对每回合的释放的飞碟数的控制

public class RoundController : MonoBehaviour
{
    IActionManager actionManager;
    DiskFactory diskFactory;
    ScoreRecorder scoreRecorder;
    int[] roundDisks;//对应回合的飞碟数
    bool isInfinite;//游戏当前模式
    int round;//游戏当前轮次
    int sendCnt;//当前已发送飞碟
    float sendTime;//发送时间
    public bool isEnd;//游戏是否结束
    // Start is called before the first frame update
    void Start()
    {
        actionManager=Singleton<CCActionManager>.Instance;
        diskFactory=Singleton<DiskFactory>.Instance;
        Debug.Log("diskFactory...\n");
        scoreRecorder=new ScoreRecorder();
        sendCnt=0;
        round=0;
        sendTime=0;
        isInfinite=false;
        isEnd=false;
        roundDisks=new int[]{3,5,8,13,21};
    }

public void Reset()
{
    sendCnt=0;
    round=0;
    sendTime=0;
    isEnd=false;
    scoreRecorder.Reset();
    //userGUI.SetMessage("");
}

public void Record(DiskData disk){
    scoreRecorder.Record(disk);
}

public int GetPoints(){
    return scoreRecorder.GetPoints();
}

public void SetMode(bool isInfinite){
    this.isInfinite=isInfinite;
}

public void setFlyMode(bool isPhysis){
    actionManager=isPhysis? Singleton<PhysisActionManager>.Instance as IActionManager: Singleton<CCActionManager>.Instance as IActionManager;
}

public void SendDisk(){//发送飞碟
    //从工厂生成一个飞碟
    GameObject disk=diskFactory.GetDisk();
    Debug.Log("getdisk...\n");
    //设置随机位置
    disk.transform.position=new Vector3(-disk.GetComponent<DiskData>().direction.x*7,UnityEngine.Random.Range(3f,8f),0);
    disk.SetActive(true);
    actionManager.Fly(disk,disk.GetComponent<DiskData>().speed,disk.GetComponent<DiskData>().direction);
}
// Update is called once per frame
void Update()
{
    sendTime+=Time.deltaTime;
    //每隔1s发送一次飞碟
    if(sendTime>1)
    {
        sendTime=0;
        //每次最多发送3个飞碟
        for(int i=0;i<2&&sendCnt<roundDisks[round];i++)
        {
            sendCnt++;
            this.SendDisk();
        }
    }
    //判断是否需要重置轮次
    if(sendCnt>=roundDisks[round]&&round==(roundDisks.Length-1))
    {//最后一轮结束
        if(isInfinite){
            round=0;
            sendCnt=0;
            isEnd=false;
        }
        else{
            isEnd=true;
        }
    }
    //更新轮次
    if(sendCnt>=roundDisks[round]&&round<(roundDisks.Length-1))
    {
        sendCnt=0;
        round++;
    }
}

}

UserGUI

用户界面与游戏的对接，包括游戏界面的呈现

public class UserGUI : MonoBehaviour
{
    IUserAction action;
    public string gameMessage ;
    int points;

void Start()
{
    Debug.Log("UserGUI...\n");
    points=0;
    gameMessage=" ";
    action=SSDirector.getInstance().currentSceneController as IUserAction;
}

public void SetMessage(string gameMessage)
{
    this.gameMessage=gameMessage;
}
public void SetPoints(int points)
{
    this.points=points;
}
private void OnGUI()
{
    //小字体
    GUIStyle fontStyle = new GUIStyle();
    fontStyle.fontSize = 30;
    fontStyle.normal.textColor = Color.white;
    //大字体
    GUIStyle bigStyle = new GUIStyle();
    bigStyle.fontSize = 50;
    bigStyle.normal.textColor = Color.white;

    if(action.Check()){
        SetMessage("GameOver!");
    }
    else{
        SetMessage("");
    }
    SetPoints(action.GetPoints());
    if (GUI.Button(new Rect(20, 50, 100, 40), "Restart"))
    {
        SetMessage("");
        //清零得分
        SetPoints(0);
        action.Restart();
    }
    if (GUI.Button(new Rect(20, 100, 100, 40), "Normal Mode"))
    {
        action.SetMode(false);
    }
    if (GUI.Button(new Rect(20, 150, 100, 40), "Infinite Mode"))
    {
        action.SetMode(true);
    }
    if (GUI.Button(new Rect(20, 200, 100, 40), "Kinematics"))
    {
        action.setFlyMode(false);
    }
    if (GUI.Button(new Rect(20, 250, 100, 40), "Physis"))
    {
        action.setFlyMode(true);
    }
    //返回鼠标点击的位置
    if(Input.GetButtonDown("Fire1"))//获取鼠标点击
    {
        Debug.Log ("Fired Pressed");
        action.Hit(Input.mousePosition);
    }
    GUI.Label(new Rect(300,30,50,200),"Hit UFO",bigStyle);
    GUI.Label(new Rect(20,0,100,50),"Points: "+points,fontStyle);
    Debug.Log("points:"+points+"\n");
    Debug.Log("message:"+gameMessage+"\n");
    GUI.Label(new Rect(310, 100, 50, 200), gameMessage, fontStyle);
}

本栏目推荐文章
• python | 小游戏 开局托儿所 自动化脚本 pyautogui
• 微软企业库Unity学习笔记(一)
• 微软企业库Unity学习笔记(二)
• 如何让Visual Studio Tools for Unity插件用于调试你自己的Mono嵌入应用程序
• 2024-01-13：用go语言，现在有一个打怪类型的游戏，这个游戏是这样的，你有n个技能， 每一个技能会有一个伤害， 同时若怪物小于等于一定的血量，则该技能可能造成双倍伤害， 每一个技能最多只能释放
• 案例分享：游戏行业各岗位的KPI绩效指标制定
• Unity 获取当前系统时间并在UI界面中显示
• 【Unity】用Graphics.DrawMeshNow在场景中画个三角形
• Unity3d_Rewired官方文档翻译：要点（四）：Rewired Editor->All Maps、Layout Rules、Map Enabler
• Unity3d_Rewired官方文档翻译：要点（二）：Rewired Editor->Setting、Tools

小游戏 unity小游戏unity qframework小游戏unity 小游戏 常用unity3d unity3 游戏角色 角色unity 游戏场景 管线 场景unity3d 误区 多人unity3d网络游戏 unity引擎2d游戏开发 撞墙判定和等候计时 小游戏 小游戏lua 游戏
